Technical Specification:

External & Internal Dimensions

• Overall Size: W1070 × D1070 × H2280 mm (All Cloud H2334 mm)
• Internal Size: W900 × D900 mm (Glass-to-glass: 1050 mm) × H2130 mm
• Weight: 265 kg
• Palletizing Dimensions: W2250 × D550 × H1235 mm (Includes pallet)
• Volume: 1.63 m³

Door & Accessibility

• Door Opening: Left-hand
• Door Closer: Yes
• Optional Feature: Occupancy indicator light

Power & Ventilation

• Power Consumption: 40W (Supports appliances up to 1000W)
• Ceiling Light: 0 – 20W
• Ventilation Rate: 1.68 m³/min, 59.3 CFM, Air change rate 50/h
• Noise Reduction: DS, A 30.3 dB (ISO 23351-1:2020)

Cooling System

• Wall Fans: 0.84W, 1500rpm × 2 (80 × 80 mm)
• Roof Fans: 3.36W, 2000rpm × 2 (140 × 140 mm)

Furniture & Features

• Bar Table (with Cup Holder): W900 × D760 × H1050 mm
• Available Colors:
  • White MFC
  • Wooden color plywood
  • Yellow powder coating
• Connectivity & Power:
  • 1 Power track (1 AC outlet)
  • 1 Wireless charging pad
  • 3m Network cable (USB module can be added)
  • Power Supply: AC 220V, USB 5V 3.1A

Premium Materials & Build Quality

• Frame: 6063 Aviation Aluminum Alloy
• Glass: Laminated (4 + 0.76PVB + 4) Glass
• Wall Structure:
  • 1.0mm Steel Surface
  • Gabriel Upholstery + Double-layer 2300g Acoustic Block
  • Soundproofing Materials: Polyester Panels, Felt, and Fabric Layers
• Roof Structure:
  • 0.8mm Steel Surface
  • Gabriel Upholstery + Double-layer 2000g Acoustic Block
• Base & Flooring:
  • E0 25 + 9mm Plywood with Black ABS Edge Banding
  • Steel Frame + Adjustable Heavy-duty Feet
  • Carpet: TPO Eco Backer + USA Global Nylon Yarn

Finishing & Coating

• Coating Type: TIGER Powder Electrostatic Spraying (Durable and scratch-resistant)

Color: Orange and Grey
